• Chainless paper belt filter + magnet filter

Chainless paper belt filter + magnet filter

FEATURES
Suitable for filtering ferrous/non-ferrous metal chip.
Filter effect varies depending on the accuracy of filter paper.
Turning the pressure roller can squeeze excess water in the paper.
Save fiter paper because of wider filtering area.
Model : P5NS6
Attach：

Taiwan patent no.

M316759/M251648/M314072/M295548

FEATURES


  •  Suitable for filtering ferrous/non-ferrous metal chip.
  • Filter effect varies depending on the accuracy of filter paper.
  • Turning the pressure roller can squeeze excess water in the paper.
  • Save fiter paper because of wider filtering area.


APPLICATION

Surface grinding machine, fine grinding machine, polishing machine,horning machine, Inner/Outer center grinding machine,Centerless grinding machine and electric discharge machine.


標準尺寸表

Model L L/Min* L W H L1 W1 H1 L2 H2 L3 H3 L4
P5NS4 100 25~40 1210 700 680 1005 600 200 1030 360 200 200 580
P5NLS6 120 50~80 1430 700 680 1225 600 200 1250 360 200 200 800
P7NS8 200 80~120 1700 900 680 1500 800 200 1450 360 200 200 1000
P7NLS12 320 120~160 1900 900 760 1700 800 280 1650 440 200 200 1200
Model HP Motor Peper width The machine models which are suitable to install this magnet filter  Including casters
P5NS4 1/8HP 25W 500 S4 附車輪
P5NLS6 1/4HP 25W 500 S6 附車輪
P7NS8 1/2HP 25W 700 S8 附車輪
P7NLS12 1HP 25W 700 S12 附車輪

*The amount of processed water is the result of the test of clean water.
※The specifications are subject to change without notice in advance.
※Special specifications can be customized.
